รองรับ 4G* FDD-LTE Cat4 (850/1800/2100/2600MHz) เครือข่าย AIS, DTAC, TRUE H, MY ความเร็วสูงสุด 150 Mbps รองรับ 3G* DC-HSPA+/HSPA+/HSPA/UMTS (850/900/2100MHz) เครือข่าย AIS, DTAC, TRUE H, MY, TOT ความเร็วสูงสุด 43.2 Mbps Dimension* 130mm*117mm*46mm（L*W*H） Net Weight* About 295 g Color* White Link Speed Rate* FDD-LTE DL/UL 150Mbps/50Mbps DC-HSPA+ DL/UL 43.2 Mbps/5.76 Mbps Megabit Wired speed rate LED* Power on/off 2.4GHz WiFi Status LAN Port Status 4G/3G Signal strength Bars Power Supply* Input:110V-220V AC 50/60Hz DC:12V/1A External Interface* Two RJ45 Ports One RJ11 Port 2FF SIM slot Button* Power on/off Reset Hole Standard&Protocol* IEEE 802.11n、IEEE 802.11g、IEEE 802.11b Antenna* Two internal Wi-Fi antennas+Two external 3G/4G antennas Wireless Link Rate* 802.11 b/g/n 300Mbps Frequency Range* 2.4GHz Basic Function* Client Filter SSID,Broadcast Channel Wireless Security* WPA-PSK/WPA2-PSK WPA/WPA2 WEP Internet Connection Type* FDD LTE/TDD LTE/WCDMA/GSM Function* Automatic APN matching according to USIM Date traffic management SMS Manager USSD Service MAC Filter DMZ DHCP 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions Browser* IE, Firefox, Google Chrome, Safari, Opera Operation System* Windows XP, Windows Vista, Windows 7, Windows 8, Mac OS X 10.5, 10.6, 10.7 and 10.8 with latest upgrades Temperature* Operating Temperature: 0℃~45℃ Storage Temperature: -30ºC~70ºC Humidity* Operating Humidity: 10% ~ 90% RH Non-condensing Storage Humidity: 5% ~ 90% RH Non-condensing Default Settings* Login IP Address: 192.168.0.1 Login User Name/Password: admin/admin SSID: Tenda_xxxx (where "xxxx" represents the last four characters of device MAC address) Password:See the label on back cover Package Content* 4G680V2.0 device RJ45 Cable RJ11 Cable Quick Install Guide Power supply 12V/1A(EU)
