**HIGHLIGHTS Concise and fashionable product appearance Economical and Environmental friendly product concepts Easy installation and configuration Support for fast ethernet – adaptive 10/100mbps network port, support POE power supply. High Interoperability – Compatible with major platforms: 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc. **GENERIC 1 SIP Line POE Enabled Handset mode Wall installation Optional External Power Supply **CALL FEATURES Call out / Answer Call Hold / Resume Call Transfer(Attended/Unattended) Redial Hot Line Hot desking **PHONE FEATURES Call logs with missed calls/ incoming calls/ outgoing calls. Max support 600 records(web) Dial without registration Action URL / Active URI Web dial **AUDIO Narrowband CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB Acoustic echo cancellation (AEC) Dynamic Adaptive Jitter Buffer up to 300ms DTMF: In-band, Out-of-Band – DTMF (RFC2833) / SIP INFO **NETWORKING 10/100Mbps Ethernet IP Configuration: Static / DHCP / PPPoE Network Access Control: 802.1x VPN: L2TP / OpenVPN VLAN QoS **PHYSICAL SPECIFICATIONS Keypad: 17 keys, including -12 Standard Phone Digits keys -5 Function keys Handset (RJ11) x1 Standard RJ11 Handset Wire x1 RJ11 Port x1: Handset x1 RJ45 Port x1: Network x1 DC Power Input:: 12V / 0.5A Power Consumption: Idle 1.6~2.3W, Peak 2.6~3.3W Working Temperature: 0~40ȭ Working Humidity: 10~95% Installation: Wall installation Color: Black Device Dimensions: 96x222x59mm Gift Box Dimensions: 302x105x67mm Outer CTN Dimensions: 445x355x325mm (20 PCS)
