System Specifications
- Wireless Standard : IEEE 802.11 b/g/n 2.4 GHz, IEEE 802.11 a/n/ac 5 GHz
- Wireless Speed : Transmit: 300 Mbps* for 2.4 GHz and 867 Mbps* for 5 GHz, Receive: 300 Mbps* for
2.4 GHz and 867 Mbps* for 5 GHz
- Wireless Security : WPA-PSK/WPA2-PSK
- WLAN Features : Guest Wi-Fi/ WiFi Protected Setup (WPS)/ WiFi Multimedia (WMM)/ Auto channel
selection/ Wireless output power management/ Wireless scheduling/ MAC address filtering
- Routing : Network Address Translation (NAT), WAN Type: Static IP, DHCP, PPPoE, PPTP, DHCP
server/client, IGMP v1/v2, Auto-IP change
- Firewall : Stateful Packet Inspection (SPI), Deny of Service (DoS)
- System Management : Online firmware upgrade, Remote management, UPnP, Dynamic DNS
Hardware Specifications
- WAN : One 10/100/1000 Mbps Ethernet RJ-45 port with auto MDI/MDIX support
- LAN : Four 10/100/1000 Mbps Ethernet RJ-45 port with auto MDI/MDIX support
- LED indicators : Power/SYS, WAN, WLAN_2.4G, WLAN_5G
- Buttons : Reset, WPS
- Power : 12VDC, 1.5A
- Power consumption : 13W
